| Temper | O, H32, H34, H36, H111, etc. |
| Width (mm) | 25, 50, 100, 150, 200, 250, etc. |
| Tensile Strength | 110 to 300 MPa (15 to 44 x 103 psi) |
| Yield Strength | 49 to 270 MPa (7.2 to 39 x 103 psi) |
| Elongation | 7.3 to 21 % |
Welcome to HuaSheng Aluminium, your reliable partner for all things related to 6063 Aluminium Strip. In the world of Aluminium alloys, the 6063 strip stands out as a versatile and widely utilized material across various industries. This in-depth guide is designed to provide a comprehensive understanding of 6063 Aluminium Strip, focusing on its properties, applications, challenges, and solutions to equip manufacturers, engineers, and end-users with the necessary knowledge for optimal utilization.
The 6063 Aluminium Strip is a heat-treatable alloy that is part of the 6xxx series. It is renowned for its superior extrudability, formability, and corrosion resistance, making it a top choice for applications that demand intricate shapes and profiles.
The properties of 6063 Aluminium Strip are what make it stand out in the industry:
| Property | Description | Advantage | Application |
| Extrudability | Capability to be extruded into complex shapes | Excellent for intricate shapes and profiles | Construction industry for architectural profiles |
| Formability | Ability to be shaped and bent | Good formability without compromising mechanical properties | Complex design applications |
| Corrosion Resistance | Resistance to corrosion | Excellent resistance for outdoor and corrosive environments | Architectural and automotive components |
| Heat Treatability | Can be heat-treated for property enhancement | Opportunities for strengthening | Structural components requiring increased strength |
| Aesthetic Appeal | Visually pleasing surface finish | Smooth surface finish | Decorative trims, furniture |
The distinct properties of 6063 Aluminium Strip are due to its specific chemical composition:
| Element | Composition Range |
|---|---|
| Aluminium, Al | <= 97.5 % |
| Chromium, Cr | <= 0.10 % |
| Copper, Cu | <= 0.10 % |
| Iron, Fe | <= 0.35 % |
| Magnesium, Mg | 0.45 – 0.90 % |
| Manganese, Mn | <= 0.10 % |
| Other, each | <= 0.05 % |
| Other, total | <= 0.15 % |
| Silicon, Si | 0.20 – 0.60 % |
| Titanium, Ti | <= 0.10 % |
| Zinc, Zn | <= 0.10 % |
The mechanical properties are vital for the performance of 6063 Aluminium Strip in various applications:
| Property | Value | Description |
| Tensile Strength | 110 to 300 MPa (15 to 44 x 103 psi) | Maximum stress under tension |
| Yield Strength | 49 to 270 MPa (7.2 to 39 x 103 psi) | Stress at plastic deformation start |
| Elongation at Break | 7.3 to 21 % | Length increase before rupture |
| Hardness (Brinell) | 25 to 95 HB | Resistance to indentation |
Understanding the physical properties is key to proper application:
| Property | Value | Description |
| Density | 2.70 g/cm³ | Indicates material compactness |
| Melting Point | 616 – 654 °C (1140 – 1210 °F) | Transformation from solid to liquid |
| Thermal Conductivity | 218 W/m·K | Ability to conduct heat |
Despite its many advantages, working with 6063 Aluminium Strip presents certain challenges:
| Issue | Description | Impact |
| Scratching and Denting | Sensitivity to surface damage | Aesthetic and structural concerns |
| Oxide Formation | Occurs during manufacturing and storage | Diminished aesthetics and potential corrosion |
| Issue | Description | Impact |
| Weld Cracking | Susceptibility during certain welding processes | Compromised structural integrity |
| Porosity | Occurs in welds | Reduced strength and corrosion susceptibility |
| Issue | Description | Impact |
| Cracking during Forming | Inadequate forming parameters | Rejected components and increased costs |
| Springback | After forming | Affects dimensional accuracy |
To overcome these challenges, HuaSheng Aluminium suggests the following strategies:
To aid in your comprehensive understanding, here are answers to common queries:
